Open-source benefits for industrial controllers

New controller options make it possible to add open-source features to industrial-grade automation. Think of industrial versions of Raspberry Pi or Arduino controllers.

By Bill Dehner May 4, 2020
Courtesy: AutomationDirect

Industrial microcontrollers are bringing open-source benefits to industrial applications even though many industrial automation technologies seem to be a frumpy distant relative of the glitzy consumer-grade hardware and software so common in our everyday lives. Industrial controller technologies are closing the gap with consumer cousinswhich is creating some significant and unexpected benefits for end users.

Industrial automation technologies, including controllers, are often portrayed as developing at a slower pace when compared with consumer technologies, and rightfully so. The lag is explained because consumer technologies only will be adopted into more conservative and rugged industrial applications after proven and accepted in the mass market.

Furthermore, because industrial applications need to reliably operate potentially dangerous equipment for years, it is more important for automation products to be carefully crafted and packaged. This means other controller features, such as ease of use and good connectivity, are often secondary considerations.

Over the past 15 years or so, a “maker” culture has gained momentum in the consumer world. This community brings a passion and creativity to using PCs and microcontrollers to operate all sorts of do-it-yourself projects. Most of these developers make these homebrew projects open source for anyone to use, but the technologies usually aren’t ready for the factory floor.

Industrialized microcontrollers now combine open source benefits with proven industrial platforms to give end users more automation options.

From PLC to PAC and beyond

A few decades ago, it was pretty clear what an industrial programmable logic controller (PLC) was, and also what it wasn’t. Compact, built for installation on machinery and connected to monitor sensors and command devices like valves, these devices helped power the third industrial evolution of automation. They often used specialized cables, communication protocols, and languages for these tasks. Even though they were relativelyclosed platforms, they were very mission specific and effectively tailored for industrial applications.

As technologies like Ethernet, faster and cheaper processors and more reliable PC operating systems became available, the consumer and industrial markets benefited.

For the manufacturing industryPLCs became more convenient and economical to use. Some vendors began marketing their most capable PLCs as programmable automation controllers (PACs) as added featuremade them suitable for a greater number of applications; greater connectivity made it possible to network more devices.

Today, computing and wireless hardware are so compact and cost-effective that even the smallest field-located sensors and devices have become intelligent and are able to communicate with each other and with supervisory systems. These smart devices make up the Industrial Internet of Things (IIoT) and there is a growing amount of processing power located at the industrial edge.

Controllers, gatewaysinput/output (I/O) modulesand smart sensors continue to be built specifically for industrial markets. But defining the capabilities and roles for PLC, PAC, edge or IIoT devices becomes a little more difficult as they each overlap to some extent.

Now, as some users look for ways to combine their opensource experiences into their industrial projectsnew industrialized products incorporating open source are leading to even more options.

Open-source processing

Opensource projects are relevant for industrial applications in many ways. For example, the common Linux opensource operating system has played an increasing role in the past few years as it is embedded within IIoT implementations and as a platform for running control and visualization software.

Figure 1: Arduinos and similar microcontrollers are a staple of the maker community, enabling many types of hobby-focused computing and automation projects. Courtesy: AutomationDirect

Figure 1: Arduinos and similar microcontrollers are a staple of the maker community, enabling many types of hobby-focused computing and automation projects. Courtesy: AutomationDirect

Opensource programmers make code snippets and entire programs available to all users, generally at no cost. Many would consider this open nature as introducing an increased risk to those implementing it. However, greater openness makes code available for anyone to inspect, and the large community of developers can provide a quick response when issues are identified.

From an open hardware standpointthe two leading microcontrollers are Raspberry Pi and Arduino. The former is more like a miniaturized single-board PC, while the latter is more barebones. For Arduinos, stackable accessory boards called shields add Ethernet, Wi-Fi, GPS, and other extended functionalitymaking these systems well suited for prototyping and hobbies (Figure 1).

Microcontrollers like the Arduino were created for students learning to program in C++ and are designed to be usable by those with any level of programming experienceAn effectively free and extensive software library, many low-cost hardware options, and an enduser design focus have made this opensource concept a favorite of the maker community.

Microcontrollers popularity has made the industrial automation industry take notice because many of the features desired by hobbyists also are needed for industrial projects. Some end users have even incorporated consumer-grade microcontrollers into industrial applications, but there is some risk involved.

Reducing open-source controller risk

As interesting as microcontrollers aremany issues prevent them from being suitable for industrial applications. A few challenges are:

  • Unprotected bare circuit board and consumer-grade design to remain economical
  • Not designed to meet temperature, vibration and electrical noise conditions present in industrial applications
  • Not extensively fieldtested in typical industrial environments
  • Lack of I/O using typical industrial signals
  • No agency approvals or industrial certifications.
Figure 2: New products, such as AutomationDirect’s ProductivityOpen, offer end users a way to combine open-source microcontroller functionality within an industrial-grade form factor using proven I/O designs. Courtesy: AutomationDirect

Figure 2: New products, such as AutomationDirect’s ProductivityOpen, offer end users a way to combine open-source microcontroller functionality within an industrial-grade form factor using proven I/O designs. Courtesy: AutomationDirect

Despite these risks, some end users are looking for ways to take advantage of opensource benefits, but in a manner robust enough for any kind of commercial or industrial application. A few industrial vendors have worked to combine opensource elements with industrial form factors so end users can realize the best of both worlds and eliminate or significantly minimize these risks (Figure 2).

Many conventional PLC form factors are already modular with I/O and other modules connecting to a processor. For example, one supplier realized they could industrialize an Arduino controller and configure it to take the place of, or supplement, traditional PLC controller. Engineers redesigned a microcontroller from the ground up with industrialized parts and assembly methods and packaged it in a protected form factor compatible with industrial I/O modules (Figure 3).

Figure 3: Unlike consumer-grade controllers, industrialized controllers like the AutomationDirect ProductivityOpen shown here, are tested in extreme conditions to ensure reliability in the field. Courtesy: AutomationDirect

Figure 3: Unlike consumer-grade controllers, industrialized controllers like the AutomationDirect ProductivityOpen shown here, are tested in extreme conditions to ensure reliability in the field. Courtesy: AutomationDirect

The result is an industrialized opensource controller that connects with industrial power supplies and I/O modules, so a configuration can be created for use in most general automation applicationsThe manufacturer also makes industrially-hardened shields and third-party commercial Arduino controller shields available for increased functionality.

Developers use a software interface maintaining Arduino sketch to program in C++. For enhanced usability, the supplier also created a draganddrop graphical programming interface (Figure 4) which simplifies the most common programming tasks. This allowed the user to work with block programming as-is or add blocks of C++ code to access more advanced programming features.

Figure 4: The addition of AutomationDirect ProductivityBlocks graphical programming software gives end users another accessible way to incorporate open-source Arduino microcontroller functionality into their industrial projects. Courtesy: AutomationDirect

Figure 4: The addition of AutomationDirect ProductivityBlocks graphical programming software gives end users another accessible way to incorporate open-source Arduino microcontroller functionality into their industrial projects. Courtesy: AutomationDirect

Open-source controller programming benefits

End users choosing open source for their automation project will certainly benefit from the mashup of contemporary programming options with proven industrial practicalities. Users can mix-and-match many ways to get just what they need.

Sometimes, it makes sense to continue using a PLC-based system, while adding an industrialized open controller networked nearby to perform specialized tasks or calculations. In some cases, users can develop all the control logic and general-purpose calculations in the open controller, and then automate associated equipment with I/O devices.

Another consideration involves design and maintenance personnel skill sets. While existing industrial users have been trained on PLCs through their careers, the next generation of users are more likely to be comfortable with contemporary technologies and programming languages used in maker hardware.

This platform can bridge open controllers with PLCs and I/O, industrial manufacturers can apply their current skillsets while growing their technical staff with new employees who would prefer to work on modern opensource platforms.

Open-source controller applications

As industrial open source gains momentum, users will continue to find new applications. A basic way to use an open controller, even for those who are new to C++, is to configure it as an inexpensive data logger. Original equipment manufacturers (OEMs) can use open controllers as an all-in-one solution for operating machinery, while incorporating more advanced algorithms and data handling than they would with a PLC.

Open source also can be a great fit for various semi-industrial applications like environmental controls or laboratory equipment monitoring. More consumer-oriented applications such as automated smoker grills, home automation and agricultural projects also become viable with industrialized opensource platforms.

For instance, a gardening hobbyist might configure a microcontroller to operate a backyard vegetable hothouse and irrigationAt work, they could use these same concepts to automate much largerscale agricultural systems and equipment. Someone using a microcontroller at home to remotely control lights and other devices also could extend the same concepts to automate lighting and environmental controls at commercial or industrial facility.

Choose controllers for industrial environments

The proliferation of consumer-grade microcontrollers might be a tempting automation choice, especially for machine manufacturers, due to the low hardware cost. However, any controller unable to withstand an industrial environment will drain support budgets because up to 20% of operating expenses are typically maintenancerelated.

Now that PLC and PAC technologies have evolved to include industrialized opensource hardware optionsend users can incorporate modern automation systems they want using the robust platforms they need.

Bill Dehner, technical marketing engineer, AutomationDirect. Edited by Chris Vavra, associate editor, Control Engineering, CFE Media and Technology, cvavra@cfemedia.com

MORE ANSWERS

Keywords: PLC, PAC, open-source controllers

Industrial automation controllers designed for the plant floor are catching up with consumer-grade models.

Open-source controllers offer many new, previously impossible options to industrial automation users.

Industrial controllers, regardless of feature, still need to be designed to withstand harsh conditions to operate properly.

ONLINE

Read this article online at www.controleng.com for additional stories from the author.

Consider this

What open-source hardware options are the most wanted on the plant floor?


Bill Dehner
Author Bio: Bill Dehner has spent the majority of his 14-year engineering career designing and installing industrial control systems for the oil and gas, power and package handling industries. He has a BSEE with an associate degree in avionics from the USAF and is currently working for AutomationDirect as a technical marketing engineer.
