Benefits of repairing versus replacing a motor
Significant savings can be made by upgrading old motors to more efficient modern alternatives, but sometimes it isn't always possible, which can lead to companies repairing the motor instead.
Motors and drives insights
- Swapping an older motor for a modern equivalent is not always practical or even possible, which can lead companies to repairing them instead.
- Motors that benefit from repair and refurbishment generally includes motor cost and availability as well as improving its efficiency.
A study carried out by the Association of Electrical & Mechanical Trades (AEMT) and the Electrical Apparatus Service Association (EASA), has shown motor efficiency can widely be maintained when a repair is carried out to a defined set of standards. The findings of the 2019 study, which have been published in a paper entitled “The Effect of Repair/Rewinding on Motor Efficiency,” established efficiency was maintained on repairs to current machines up to IE3 efficiency. This guide has been incorporated into the latest international repair standard IEC 60034:23:2019 and the latest American ANSI/EASA standard, AR100.
There are, however, some circumstances where the efficiency of a motor can be improved by refurbishment and rewinding. This generally applies to older, less efficient motors and the decision to repair rather than replace typically involves a broader range of factors than simply to improve efficiency.
Generally, the most effective way to improve a motor’s efficiency is adding more copper to its coils. It is often possible to add more copper to a set of coils, or, more specifically, increase the copper cross-sectional area. This is achieved through the very tight tolerances modern coils can be manufactured to and the ability of state-of-the-art computer-aided design (CAD) systems to optimize coil design.
This has several benefits, such as reducing the coil’s resistance, increasing the potential output, and reducing the operating temperature of the machine, which can increase an asset’s life.
However, it is important to understand adding more copper will affect other characteristics in a motor which may require the wider system to be adapted. Adding more copper into a machine will affect not only efficiency but also other parameters. For example, an increased inrush-current, which might be in conflict with existing protective measures, should be expected.
The ability to increase the amount of copper in a motor has been supported by advancements in insulation materials, which means less insulation is required, and therefore space in the motors’ slots becomes available. The thickness of insulation needed for various voltage systems has significantly decreased over the years, and modern insulation systems can offer 15% reductions in thickness. As this is on the outside of the coil, the effect on the copper cross-sectional area can be greater still. Furthermore, these thinner insulations assist with heat dissipation and can again offer both an increased asset life and improved efficiency of the coils.
It is worth noting, however, that care is needed when comparing pre- and post-repair efficiency levels in a motor. Efficiency should not be compared simply by looking at a motor’s datasheets. Before a 2007 update of the IEC/EN 60034-2-1 standard, which defines methods of determining a rotating machine’s efficiency, efficiency figures were more generous due to how certain effects could be calculated out. Efficiency levels could previously be calculated with smaller additional losses than today – a standard 0.5% of absorbed power, regardless of the motor output.
Since the 2007 update, the methods have become much stricter. Now stray load losses have to be determined by a factor that reflects the motor’s output, ranging from 0.5% (≤1MW) to 2.5% (≥10MW). So, to avoid potentially misleading comparisons calculated from individual losses, efficiency should be measured directly at nominal load.
The decision on whether to repair or replace a motor typically involves several factors. These can include cost, the availability of a suitable replacement, system compatibility and, of course, efficiency. So, while increased efficiency is possible in certain circumstances, it is not often the only reason to carry out a motor repair. If efficiency is one advantage from a motor refurbishment, it may well be available, but users need to take care when calculating the actual benefits they can gain.
